Hyperelastic beta titanium wires in produce glass frame application
- group name
- Titanium Coil Wires
- Min Order
- 1 kilogram
- brand name
- MMR Parts Processing | Custom Parts Manufacturing
- Nearest port for product export
- shanghai, tianjin, xi'an
- Delivery clauses under the trade mode
- FOB, CFR, CIF, EXW
- Acceptable payment methods
- T/T, L/C, Westem Union, Cash
- update time
- Thu, 21 Nov 2024 16:54:46 GMT
Paramtents
Grade Ti-15V-3Al-3Cr-3Sn
Diameter 0.03mm - 5.0mm
Length Coils for Customers Requests
Technology Hot-Rolled, Cold-Rolled, Machining
Condition, Hot rolled(R), Annealed (M) Cold rolled(Y)
Surface Pickling surface, Polished surface, Black surface
Specifications Glass frame, Industrial
Packging & Delivery
-
Min Order1 kilogram
Briefing
We are titanium fine wire manufacture ,we supply bending titanium wire and twisted titanium wire service.
Detailed
AS a titanium wire company supplier, we have been strictly inspected and the quality is guaranteed. titanium wire used in manay field for industry.our hot sell titanium wire size are titanium wire 1mm and titanium wire 2mm .will will try out best to give you good services. The following are detailed information about our wires.
Chemical composition
Grade | Chemical composition, weight percent (%) | ||||||||||||||
|
C ≤ |
O ≤ | N ≤ |
H ≤ |
Fe ≤ | Al | V |
Sn |
Cr | Ni | Mo | Other Elements Max. each | Other Elements Max. total | |||
Ti15333 | 0.05 | 0.15 | 0.05 | 0.015 | 0.25 | 2.5～3.5 | 14.0～16.0 | 2.5～3.5 | 2.5～3.5 | — | — | 0.1 | 0.4 | ||
Physical properties
Grade | Physical properties | ||||||
|
Tensile strength Min |
Yield strength (0.2%, offset) |
Elongation in 50mm Min (%) |
|||||
ksi | MPa | Min | Max | ||||
ksi | MPa | ksi | MPa | ||||
Ti15333 | — | 705～945 | — | 690 | — | 835 | 10 |
Tolerance (mm)
Diameter | 0.1~0.2 | 0.3~0.5 | 0.6~1.0 | 1.1~2.0 | 2.1~4.0 | 4.1~5.0 |
Tolerance | -0.025 | -0.04 | -0.06 | -0.08 | -0.1 | -0.14 |
Testing :
Chemical composition test,
Physical properties test,
Appearance defects inspection,
Eddy current testing.
Aerospace alloys and applications，
Glass frame，
Sport industry，
Piercing & Accessory，
Surgical instruments，
Architectural applications，
Features :
High tensile strength;
High corrosion resistance;
Low density, good thermal stability;
Non-ferromagnetic;
Good bio-compatibility;
High temperature and low temperature resistance;
High resistance to strong acid and strong alkali and so on.
What we can do for you?
- If the above model is not suitable for your workpiece, please tell us your need and then we can send you the most satisfying drawing.
